These affordable, full-featured pumps are designed for low to medium volume applications and perfect for a portable dispense solution. LD pumps are fine-tuned for a compact, flexible and durable solution pumping grease up to NLGI #2 up to 4.5lbs/minute. The pump featured is for a 35lb pail. Most often used in automotive dealerships, fast lube centers, service shops and lube trucks.



Features

• Three inch air motor providing more power for a better flow
• Patented cup and plate design eliminates the need for O-rings that wear faster for a more durable, long-lasting solution
• Modular air valves are easy to configure for hassle free installation
• Patented self cleaning design increases reliability and minimizes pressure drop with rapid change over for reduced stalling and smoother flow
• 5 Year Warranty. See manufacturers website for details.
• Approximate Free Flow Rate: @ 100 psi 4.5 lb./min (2 kg/min)
• Approximate Air Use and Flow @ 100 psi (80 cpm): 16 scfm @ 1.7 gpm (0.45 m ³/min @ 10.6 lpm)
• Air Inlet: 1/4 in npt (f)
• Fluid Outlet: 1/4 in npt (f)
• Air Operation Range: 20-150 psi (1.37-10 bar)
• Cycles per Pound/Kg: 47 cpp / 103 cpk
• Wetted Parts: Steel, brass, nitrile rubber, polyurethane, UHMWPE, aceta



Technical

Weight approx.	15	lbs
Dimensions (L x W x H)	25.2 x 7.2 x 9.6	inch



Options

11-24G603	Graco 24G603 LD Series 50:1 - 120 lb Pneumatic Grease Pump	$861.00	Add to cart
11-24G606	Graco 24G606 LD Series 50:1 - 400 lb Pneumatic Grease Pump	$940.00	Add to cart



Accessories

11-24H862

Graco 24H862 LD Series Grease Pump Hose Kit - 6 ft

$196.00

Add to cart
