The dispense meter is durable and easy to use, giving technicians everything they need at their fingertips. PINs and other data can be entered in moments via a larger, more intuitive display. NFC tags can be used for immediate PIN entry and faster access to work orders.



Features

• Faster PIN entry with built-in NFC reader and simple, efficient controls.
• Large high-contrast display for low and bright-light conditions.
• Communicates dispense information wirelessly with Hub.
• All meters come standard with your choice of a rigid or flexible fluid extension. The meter featured includes a rigid extension (see additional options below) and automatic flush-mount nozzle design that re-seats after dispense to prevent contamination.
• Long battery life, requires four standard AA batteries
• 5 year warranty. See manufacturer’s website for details.
• Flow Range*: 0.25 to 18 gpm (0.9 to 68 lpm) *Tested in 10W motor oil. Flow rates vary with fluid pressure, temperature and viscosity.
• Maximum Working Pressure: 1,500 psi (103.4 bar)
• Units of Measure (factory set to quarts): Pints, quarts, gallons, liters
• Inlet: 1/2 in NPT
• Operating Temperature Range: 4°F to 158°F (-16°C to 70°C)
• Wetted Parts: Aluminum, stainless steel, PBT, nitrile rubber, zinc-plated carbon steel, nickel-plated carbon steel



Technical

Weight approx.	6.6	lbs
Dimensions (L x W x H)	16 x 5.5 x 7	inch



Options

11-25M324

Graco 25M324 Pulse™ Fluid Management Electronic Oil / Anti-Freeze Meter 1/2" NPT - Flexible Extension

$1,794.00

Add to cart



Accessories

11-131226	Graco 131226 Pulse™ / SD™ Meter Boot	$118.00	Add to cart
11-131462	Graco 131462 Pulse™ Fluid Management NFC Tags - 25-Pack, Blue	$124.00	Add to cart
11-15T366	Graco 15T366 Impact Protection Swivel Cover - Black	$29.00	Add to cart
11-15T367	Graco 15T367 Red Impact Protection Swivel Cover	$29.00	Add to cart
11-15T368	Graco 15T368 Blue Impact Protection Swivel Cover	$29.00	Add to cart
11-15T369	Graco 15T369 Green Impact Protection Swivel Cover	$29.00	Add to cart
11-15T370	Graco 15T370 Yellow Impact Protection Swivel Cover	$29.00	Add to cart
