The 5:1 ratio Panther® pump is suitable for simultaneous fluid distribution of up to four dispense points, or for pumping to distances of up to 750 feet. Maximum simultaneous dispense points @ 1.5 gal/m (5.7 l/m) per dispense point. Note: pumping distance and pipe diameter will effect dispensing performance. The Panther's air motor features a precision air reversing valve mechanism with dual valve ports for improved high speed breathing. It also contains a positive trip detent spool mechanism that eliminates stalling (blowing air) when the pump is caught between strokes. It has a simple yet durable construction with all internal parts lubricated at the factory using a life-tested synthetic grease (Balcrank® P/N 826733). This grease coats all internal parts and repels air line moisture to inhibit corrosion. The Panther® pumping assembly features a nitrided steel pump rod and foot valve for superior wear and corrosion resistance. The pump's exterior is constructed from aircraft grade extruded aluminum for an outstanding strength-to weight ratio. The pump also has high quality Buna-N seals and is packaged in a pump that has proven reliable yet easy to service and maintain.



Features

• Bare Panther HP 5:1 Pump
• 10' x 1/2" Fluid Hose MP
• Suction Tube
• Non-metered control handle with Flex-M 1/4-turn manual extension
• Mini filter regulator with auto drain 1/4" NPT(F)
• 1/4" Air nipple and coupler



Technical

Weight approx.	24	lbs
Power supply	air	V/Hz/A
